Description

SynthMaster 2 is a two layer 'all-around' semi-modular software synthesizer and effect plug-in that comes with 2000 factory presets right out of the box. It features many different synthesis methods including VA, Additive, Wavetable, Wavescanning, Phase Modulation, Frequency Modulation, Pulse Width Modulation, Ring Modulation, Amplitude Modulation, Physical Modeling and SFZ Sample Playback synthesis.

Cross Platform

SynthMaster runs as a VST, AAX instrument on both Windows and Mac OSX, and also as an Audio Unit instrument on Mac OSX.

Oscillators

Stereo Oscillators with Unison/Voice Stacking: Oscillators in SynthMaster have stereo output. Using the "voices", "voices mix", "detune curve", "detune spread", "pan stread", "tone spread" and "phase spread" parameters, each basic/wavetable oscillator can generate a rich "supersaw" type sound.

Basic Oscillators

Basic oscillators in SynthMaster are capable of synthesizing many different types of waveforms: Sine, Square, Triangle, Sawtooth, Pulse, Noise, single cycle waveforms and multisampled WAV/AIFFs defined in SFZ files. Each oscillator comes with 17 different algorithms in the following categories: Spectral (LP, HP, LS, HS, BP, BS), Bend (Bend+, Bend-, Bend+/-), Sync (Rect Window, Half Cos Window, Cos Window, Tri Window, Saw Window), Pulse (Pulse1, Pulse2) and Quantize.

• Sine, Square, Triangle, Sawtooth, Pulse, Noise
• Single cycle waveforms
• Multisampled WAV/AIFFs defined in SFZ files

Wavetable Oscillators

A 'Wavetable' oscillator is similar to a basic oscillator, except that the waveform can be scanned (interpolated) through up to 256 different waveforms shapes. The position of the waveform can be adjusted using the 'wave index' parameter. Starting with version 2.9, SynthMaster now supports loading wavetables from wave files!

• Contains many wavetables
• You can import your own wavetables by drag and drop

Additive and Vector Oscillators

An 'Additive' oscillator is actualy 8 'basic' oscillators running together. Each 'basic' oscillator has its own detune, tone, phase/pulse width/algorithm parameter, frequency, waveform type and algorithm parameters.

A 'Vector' oscillator consists of 4 'basic' oscillators, mixed at different ratios. The mix ratios are determined by 2 orthogonal parameters in 2 dimensions: 'X Index' and 'Y index'.

Semi Modular Architecture

For each SynthMaster instance, there are 2 layers followed by 2 global effect send busses. The modulators can modulate frequency, phase, amplitude or pulse width of the oscillators or any other modulators at audio rate, or they can be used as regular oscillators. Each layer has its own:

• Arpeggiator
• 2 Oscillators
• 4 Modulators
• 2 Filters
• 4 ADSR Envelopes
• 2 Multistage Envelopes
• 2 2D Envelopes
• 2 LFOs
• 4 Keyscalers

Massive Modulation Architecture

SynthMaster has more hundreds of modulation targets and 48 modulation sources including ADSR Envelopes, 2D Envelopes, Multistage Envelopes, LFOs, KeyScalers, Easy Parameters, Vocoder Bands, MIDI Velocity, Aftertouch, Pitch Bend and MIDI CC. The modulation matrix, which has 64 available slots, has visual filtering as well so that targets for a specific source, or sources for a specific target can be filtered and shown on the user interface.

• ADSR Envelopes
• 2D Envelopes
• Multistage Envelopes
• LFOs
• KeyScalers
• Vocoder Bands
• MIDI Velocity
• Aftertouch
• Pitch Bend and MIDI CC

Filters

Zero Delay Feedback Filters: All of the 4 new filter categories in SynthMaster are developed using the zero delay feedback filter technology. With advanced filter parameters like input gain, drive and acid, you can get that "analog" sound from the filters!

VAnalog Filters

The 'VAnalog' filters are modelled after the famous ladder filter, so they self oscillate when the filter resonance is maxed out. They have continuosly variable slope, which is unique to SynthMaster. They have 3 different CPU settings: "Basic", "Normal" and "High". The Basic setting sounds similar to the other algorithms in most cases and consumes at least 50% less CPU.

Multimode Filters

With the new 'multimode' filter type, it is possible to switch from Lowpass to Bandpass to Highpass filter types continuously. For analog multimode filters, it is also possible to change the slope of the filter continously from 0 db/oct to 24 db/oct.

Dual Filters

With the new 'dual' filter type, two multimode filters can be run simultaneously, either in parallel, or in series. The mix ratios between the filters, and the topology (parallel/series) between them can be changed continuosly, as well as the modes and cutoff frequencies of the filters.

Comb Filters

Comb filters are digital filters used in physical modeling synthesis.

Effects

Rich set of Effects: SynthMaster features 11 different effect types: Distortion, LoFi, Ensemble, Phaser, 6 Band EQ, Compressor, Vocoder, Delay, Chorus, Tremolo, Reverb.

11 types of effects

Distortion, LoFi, Ensemble, Phaser, 6 Band EQ, Compressor, Vocoder, Delay, Chorus, Tremolo, Reverb.

Flexible Effects Routing

Each of the 11 effect types can be inserted on any layer insert or on any of the 2 global effect bus inserts.

Before/Inside/After Filter Distortion

A distortion stage can be inserted before, after, or even inside the filters. For analog filters, the distortion is applied for each of the 4 filter stages in 'inside' mode.
